Technical specifications
10
Table 10- 1 Construction
Type Dimensions (W x H x D) in
mm
Weight in g Installation options
- DIN rail
- S7-300 standard rail
- Wall mounting
XF204 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X208 60 x 125 x 124 780 +
XF208 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X216 120 x 125 x 124 1200 +
X224 180 x 125 x 124 1600 +
X204-2 60 x 125 x 124 780 +
X204-2TS 60 x 125 x 124 780 +
XF204-2 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X206-1 60 x 125 x 124 780 +
XF206-1 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X212-2 120 x 125 x 124 1200 +
X204-2LD 60 x 125 x 124 780 +
X206-1LD 60 x 125 x 124 780 +
X212-2LD 120 x 125 x 124 1200 +
X202-2IRT 60 x 125 x 124 780 +
X204IRT 60 x 125 x 124 780 +
XF204IRT 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X204 IRT PRO 90 x 125 x 124 1000 +
X202-2P IRT PRO 90 x 125 x 124 1000 +
X201-3P IRT PRO 90 x 125 x 124 1000 +
X202-2P IRT 60 x 125 x 124 780 +
X201-3P IRT 60 x 125 x 124 780 +
X200-4P IRT 60 x 125 x 124 780 +
SCALANCE X-200
Operating Instructions, 12/2011, A5E00349864-19
275
