Siemens SCALANCE X-200

Technical specifications
SCALANCE X-200
276 Operating Instructions, 12/2011, A5E00349864-19
Table 10- 2 Ports
Type Connectors end devices or
network components via
twisted pair
RJ-45 jacks with MDI X
pinning
10/100 Mbps (half / full
duplex)
Connections for end
devices or network
components via FO cable
BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
Connectors for power
supply
4-pin plug-in terminal block
Connectors for
signaling contact
2-pin plug-in terminal block
XF204 4 - 1 1
X208 8 - 1 1
XF208 8 - 1 1
X216 16 - 1 1
X224 24 - 1 1
X204-2 4 2 1 1
X204-2TS 4 2 1 1
XF204-2 4 2 1 1
X206-1 6 1 1 1
XF206-1 6 1 1 1
X212-2 12 2 1 1
X204-2LD 4 2 1 1
X206-1LD 6 1 1 1
X212-2LD 12 2 1 1
X202-2IRT 2 2 1 1
X204IRT 4 - 1 1
XF204IRT 4 - 1 1
Type Connectors end devices or
network components via
twisted pair
RJ-45 jacks with MDI X
pinning
10/100 Mbps (half / full
duplex)
Connections for end
devices or network
components via FO cable
SC RJ jacks (push-pull)
(100 Mbps, full duplex to
100BaseFX)
Connector for power supply
4-pin plug-in terminal block
Connector for
signaling contact
2-pin plug-in terminal block
X202-2P IRT 2 2 1 1
X201-3P IRT 1 3 1 1
X200-4P IRT - 4 1 1
Type Connectors end devices or
network components via
twisted pair
RJ-45 jacks with MDI X
pinning
10/100 Mbps (half / full
duplex)
Connections for end
devices or network
components via FO cable
SC RJ jacks (push-pull)
(100 Mbps, full duplex to
100BaseFX)
Connector for power supply
5-pin Power PLUG Pro
connector (male)
Connector for
signaling contact
5-pin b-coded M12
connector (male)
X204 IRT PRO 4 - 2 1
X202-2P IRT PRO 2 2 2 1
X201-3P IRT PRO 1 3 2 1
