Siemens SCALANCE X-200 User Manual

Connection
5.1 Power supply
SCALANCE X-200
Operating Instructions, 12/2011, A5E00349864-19
137
Figure 5-1 Mounting position for operation under marginal conditions
Table 5- 1 Operation under marginal conditions
Environment Max Power 1 (L1+, N1) Max Power 2 (L2+, N2)
+40℃ 16 A 16 A
+50℃ 12 A 12 A
+60℃ 8 A 8 A
SCALANCE X204 IRT PRO only
+70°C 6 A 6 A
