Connection
5.4 Fitting the IE FC RJ-45 Plug 180
SCALANCE X-200
144 Operating Instructions, 12/2011, A5E00349864-19
Removing the IE FC RJ-45 Plug 180
1. Press on the locking mechanism of the IE FC RJ-45 Plug 180 gently to remove the plug.
Figure 5-4 Releasing the RJ-45 Plug
If there is not enough space to release the lock with your hand, you can also use a 2.5 mm
screwdriver. You can then remove the IE FC RJ-45 Plug 180 from the twisted pair socket.
Figure 5-5 Releasing the RJ-45 Plug with a screwdriver
