Configuration / diagnostics using remote mechanisms
6.3 Configuration using Web Based Management (WBM) and Command Line Interface (CLI)
SCALANCE X-200
184 Operating Instructions, 12/2011, A5E00349864-19
Ring Redundancy Manager
Here you can choose whether the "active" status of the redundancy manager triggers an
error.
Standby Manager (only SCALANCE X200IRT)
Here, you can choose whether the "master" status and "passive" or "slave" and "active" or
partner not found triggers an error.
Enable Link Down Monitoring
Error message when the status of the port is "Link down". Here, you can enable/disable
monitoring of the link status for the individual ports.
Enable Link Up Monitoring
Error message when the status of the port is "Link up". Here, you can enable/disable
monitoring of the link status for the individual ports.
Note
With the default setting as supplied, no port is monitored; in other words, the fault mask is
empty.
As default, the power supply is also not monitored.
Syntax of the Command Line Interface
Table 6- 11 Fault Mask - CLI\X200>
Command Description Comment
info Displays information on the "X-200" menu item.
fault Displays the fault status.
downmask <1-n> <E¦D> Specifies a port mask for the ports for which the
monitoring of a link down event is enabled.
Administrator only.
upmask <1-n> <E¦D> Specifies a port mask for the ports for which the
monitoring of a link up event is enabled.
Administrator only.
others <P> <E¦D> Specifies the fault mask for:
P - power mask
Administrator only.
