PROFINET IO functionality
8.4 Structure of the data records
SCALANCE X-200
Operating Instructions, 12/2011, A5E00349864-19
261
Value (hexadecimal) Meaning
0x00000000 Reserved
0x00000001 – 0x7FFFFFFF Cable delay in nanoseconds.
PeerMACAddress
MAC address of the neighboring device.
MAUType
Value (hexadecimal) Meaning
0x0000 – 0x0004 Reserved
0x0005 10BASET
0x0006-0x0009 Reserved
0x000A 10BASETXHD
0x000B 10BASETXFD
0x000C 10BASEFLHD
0x000D 10BASEFLFD
0x000F 100BASETXHD
0x0010 100BASETXFD (default)
0x0011 100BASEFXHD
0x0012 100BASEFXFD
0x0013 – 0x0014 Reserved
0x0015 1000BASEXHD
0x0016 1000BASEXFD
0x0017 1000BASELXHD
0x0018 1000BASELXFD
0x0019 1000BASESXHD
0x001A 1000BASESXFD
0x001B – 0x001C Reserved
0x001D 1000BASETHD
0x001E 1000BASETFD
0x001F 10GigBASEFX
0x0020 – 0x002D Reserved
0x002E 100BASELX10
0x002F – 0x0035 Reserved
0x0036 100BASEPXFD
0x0037 – 0xFFFF Reserved
DomainBoundary
Specifies which multicast addresses are blocked.
