Expanding and assigning parameters to the device
6.4 Expansion modules (M.2)
SIMATIC IPC PX-39A
Operating Instructions, 08/2022, A5E51699601-AA
71
Reinstall the SSD drive bay. To do so, in-
sert it from the top at the respective lo-
cation in the device and plug in the
connector.
: Be careful not to damage the ca-
Reinstall the marked screw.
Close the device as specified in section "Opening the Device (Page 61)" or "Open device
with expansion slot (Page 63)".
Procedure - Removal
Proceed in reverse order of installation.
Configuring BIOS setup
You may need to make settings in the BIOS Setup. For detailed information about installation,
please refer to the documentation provided with the specific expansion module.
