Product description
1.4 External design of the device
Operating Instructions, 01/2021, A5E43920357-AA
27
No.
Connection socket
⑧
USB 3.1 Gen 2; Type C
2
backwards compatible to USB 3.0 / 2.0 / 1.1; each 1500 mA / high current
1
• (X63)
⑨
USB 3.1 Gen 2; Type A
SuperSpeed; backwards compatible to USB 3.0 / 2.0 / 1.1; each 900 mA / high current
1
• (X60)
⑩
USB 3.1 Gen 2; Type C
2
backwards compatible to USB 3.0 / 2.0 / 1.1; each 1500 mA / high current
1
•
(X61)
⑪
DisplayPort (labeling on the device: DPP), for connecting monitors to internal graphics card
• DPP 2 (X72)
•
DPP 1 (X71)
⑫
DVI-D (X70), for connecting monitors to internal graphics card
1
Sum of the currents on the USB interfaces of the device
(including the internal USB interfaces) ≤ 3 A
2
Maximum cable length: max3 m; depending on the attenuation of the cable and the maximum
data rate of the connection.
Use the original connection technology of the I/O devices to be connected
without adapters and without extensions.
Connections of the optional graphics cards
The optional graphics card is an expansion card. After installing this expansion card, the
following connections are available on the back of the device (Page 23) in the area of the
expansion cards for the connection of monitors.
• Optional graphics card P400: 3 x Mini Display Port
• Optional graphics card P2200: 4 x DisplayPort
For information on how to connect monitors with adapters to these ports, see "Hardware
accessories (Page 35)".
You can find information on the optional graphics cards under "Technical specifications of
graphic (Page 156)".
