Configuring with Web Based Management
4.3 "Information" menu
SCALANCE SC-600 Web Based Management (WBM)
Configuration Manual, 10/2021, C79000-G8976-C475-03
117
Description of the displayed values
The table contains the following columns:
• Name
Shows the name of the OpenVPN connection.
• Remote Server
Shows the IP address or the hostname of the OpenVPN server.
• Tunnel Interface IP
Shows the IP address of the virtual tunnel interface.
• Exported Subnets
Shows the IP address of the local subnets.
• Routed Subnets
Shows the subnets of the OpenVPN server.
• Status
Shows the status of the OpenVPN connection.
4.3.18.2 Server
The WBM page shows the status of the activated OpenVPN server.
Description of the displayed values
The table contains the following columns:
• Name
Shows the name of the OpenVPN server.
• Server Port
Shows the port via which the OpenVPN server sends data.
• Certificate CN
Shows the "Common Name" of the certificate used. The Common Name designates
the domain for which the certificate is issued.
• Client IP address
Shows the IP address of the OpenVPN server.
