Configuring with Web Based Management
4.7 "Security" menu
SCALANCE SC-600 Web Based Management (WBM)
300 Configuration Manual, 10/2021, C79000-G8976-C475-03
• RADIUS VLAN Assignment Allowed
Select the required setting. If "No Change" is selected, the entry in table 2 remains
unchanged.
Note
The VLAN assignment of RADIUS is only applied if the port has not already been
configured for this VLAN. If the port VLAN ID matches the VLAN ID assigned by
RADIUS, the type of membership in this VLAN must be preconfigured.
• MAC Auth. Max Allowed Addresses
Specify how many MAC addresses can communicate on the port at the same time.
If "No Change" is selected, the entry in table 2 remains unchanged.
• Copy to Table
When you click the button, the settings are adopted for all ports of table 2.
Table 2 has the following columns:
• Port
This column lists all the ports available on this device.
• 802.1X Auth. Control
Specify the authentication of the port:
– Force Unauthorized
Data traffic via the port is blocked.
– Force Authorized
Data traffic via the port is allowed without any restrictions.
Default setting
– Auto
End devices are authenticated on the port with the "802.1X" method.
The data traffic via the port is permitted or blocked depending on the
authentication result.
• 802.1X Re-Authentication
Enable this option if you want reauthentication of an already authenticated end
device to be repeated cyclically.
• Re-Authentication Timeout
Specify the time interval in seconds after which the device is reauthenticated at the
relevant port. The default value is 3600 seconds.
• Tx Timeout
The value specifies the period of time in seconds after which an EAP request packet
is sent if no client responds. If MAC authentication is enabled, a switch is made from
802.1X authentication to MAC authentication after the third EAP request packet. The
default value is 5 seconds.
