Siemens SIMATIC NET SCALANCE SC632-2C

Technical basics
3.8 Security functions
SCALANCE SC-600 Web Based Management (WBM)
Configuration Manual, 10/2021, C79000-G8976-C475-03
67
Type of
notification
Digital
In
VPN tunnel Behavior if there is a status change
Fault LED
x
-
The fault LED lights up on the device.
Read out the
status of the
MIB variable
x
-
Using the private MIB variable snMspsDigitalInputLevel, you can read out
the status of the digital input.
• OID of the private MIB variable snMspsDigitalInputLevel:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(
1).siemens(4329).industrialComProducts(20).iComPlatforms
(1).simaticNet(1).snMsps(1).snMspsCommon(1).snMspsDigita
lIO(39).snMspsDigitalIOObjects(1).snMspsDigitalInputTabl
e(2).snMspsDigitalInputEntry(1).snMspsDigitalInputLevel(
6)
• values of the MIB variable
– 1: Signal 0 at the digital input (DI)
– 2: Signal 1 at the digital input (DI)
