menus as previously. The second tab "Favorites" contains all the pages/tabs that you
selected as favorites. On the "Favorites" tab the pages/tabs are arranged according
to the structure in the "Menu" tab.
To do this, click the
button on the relevant pages/tabs.
If you disable all the favorites you have created, the "Favorites" tab is removed again.
You can save, upload and delete the favorites configuration of a device on the
"System > Load&Save" page using HTTP, TFTP or SFTP.
• Update on
/ Update off
WBM pages with overview lists can also have the "Update" button.
With this button, you can enable or disable updating of the content area. If updating is
turned on, the display is updated every 2 seconds. To disable the update, click "On".
Instead of "On", "Off" is displayed. As default, updating is always enabled on the
WBM page.
Navigation area (3)
In the navigation area, you have various menus available. Click the individual menus to
display the submenus. The submenus contain pages on which information is available or
with which you can create configurations. These pages are always displayed in the
content area.
Content area (4)
In the navigation area, click a menu to display the pages of the WBM in the content area.
Below the device image, the following entries are possible:
• PROFINET Name of Station Shows the PROFINET device name.
• System Name: System name of the device.
• Device Type: Shows the type designation of the device.
• Power Supply 1 / Power Supply 2
– Up
Power supply 1 or 2 is applied.
– Down
Power supply 1 or 2 is not applied or is below the permitted voltage.
• PLUG Configuration Shows the status of the configuration data on the PLUG, refer
to the section "System > PLUG > Configuration".
• PLUG License Shows the status of the license on the PLUG, refer to the section
"System > PLUG > License".
