Process Control System PCS 7 - PCS 7 BOX
A5E00272813-01
3-1
3 Structure of SIMATIC PCS 7 BOX
3.1 Hardware Components of SIMATIC PCS 7 BOX
SIMATIC PCS 7 BOX is supplied with the following standard hardware.
Technical Specifications of the Box PC 620
Device/Component Model
Processor Intel Pentium III; 1.26 GHz, 133 MHz FSB, 512KB SLC;
PROFIBUS/MPI; TTY
Main memory 1GB SDRAM-133 (including graphic memory)
Hard disk 80 GB HDD EIDE
Partitions:
C:\ 10 GB PCS 7 partition NTFS;
D:\ 70 GB user partition NTFS
DVD-ROM/CD-R/RW 8/8/24 speed combo drive
Graphics 8MB AGP; 1280 x 1024 at 85 Hz
Ethernet 100 Mbps Fast Ethernet; RJ45 on board
PROFIBUS CP 5611 compatible on board
Automation system (AS) and
PS extension board
Installed as PCI card, SIMATIC S7 CPU 416-2 PCI with
firmware version 3.4
DC 5 V for power supply for CPU 416-2 PCI
DC 12 V for power supply for PC fan
Serial port RS232; 9-pin; COM2
Standard ports for Mouse, keyboard and printer
Floppy drive 3,5 " 1.44 MB
External power supply unit 24 volt DC industrial power supply 85 W
