Structure of SIMATIC PCS 7 BOX
Process Control System PCS 7 - PCS 7 BOX
A5E00272813-01
3-3
3.2 Software Components of SIMATIC PCS 7 BOX
Preinstalled Software Components of SIMATIC PCS 7 BOX
• Windows 2000 Professional with Service Pack 4 Multi-language
• Software components of SIMATIC PCS 7 - PCS 7 Toolset CD
- PCS 7 Single Station consisting of all PCS 7 software components
- SIMATIC Process Device Manager (PDM)
• Software "WinAC 3.4 for SIMATIC S7 CPU 416-2 PCI"
Authorizations Required for SIMATIC PCS 7 BOX
Authorizations are based on the configuration used and number of process objects
(PO). You activate the preinstalled SIMATIC PCS 7 V6.0 SP3 software with the
corresponding authorization diskette.
• Configuration variants: SIMATIC PCS 7 BOX as AS/ES/OS station, single
station system
Software components Small-scale
authorization
Number of PO/Tags
Large-scale
authorization
Number of PO/Tags
ES (Engineering Station) 250 2000
OS (Operator Station, WinCC) 250 2000
• Configuration variants: SIMATIC PCS 7 BOX as AS/OS station with external
ES and in a PCS 7 network
Software components Small-scale
authorization
Number of PO/Tags
Large-scale
authorization
Number of PO/Tags
OS (Operator Station, WinCC) 250 2000
• Process Device Manager
The pre-installed PDM software on the SIMATIC PCS 7 BOX station is
activated by an authorization that must be purchased separately.
