Commissioning and Configuration
Process Control System PCS 7 - PCS 7 BOX
A5E00272813-01
4-9
4.2.6 Step 6: Configuring NetPro
No connection is explicitly configured in NetPro for accessing intelligent field
devices connected through the PROFIBUS via the PDM. The CP 5611 of the PC
station only needs to be connected to the DP line of the CPU 416-2 PCI. A
connection between the WinCC application and the CPU 416-2 PCI is also
configured.
Note
For access to DP slaves via the PDM, the access point "S7ONLINE (STEP 7)"
must be set to the CP5611 interface (PROFIBUS).
Ref
er to the section "Checking if the PG/PC interface is set to PC internal" for more
information about configuring the PG/PC interface.
Requirement
• The configuration in HW Config has to be completed, saved and compiled.
Follow These Steps:
1. In the SIMATIC Manager, open the NetPro by selecting the menu command
Options > Configure network. You can close the displayed "Multiproject"
dialog.
2. Select the square of the CP 5611 within the PC station and drag it onto the
PROFIBUS. Release the mouse button there.
3. Right click on the CPU 5611 within the PC station again to open the context
menu and select the command "Object Properties".
4. Click on the "Properties" button in the "Properties - CP 5611" dialog of the
"General" tab.
5. Assign an available address, for example, address 3, and close the dialog with
the "OK" button. Then click "OK" again.
6. Right click on the WinCC application within the SIMATIC PC station to open
the context menu and select the command "Insert New Connection".
7. Accept the default settings in the "Insert New Connection" dialog and click
"OK".
8. In the field "Identification Connection" of the displayed "Properties - S7
Connection" dialog, enter a name such as "Locale_S7_Connection_1" under
"Local ID:". Otherwise, accept the default settings and click on the "OK" button.
9. Save and compile your configuration.
