Additional Commissioning and Configuration
Process Control System PCS 7 - PCS 7 BOX
5-14 A5E00272813-01
5.2.2 Step 1: Configuring the PC Stations Using the Commissioning
Wizard
The Commissioning Wizard (CW) automatically appears on the SIMATIC PCS 7
BOX station following the installation of SIMATIC PCS 7 V6.0 SP3 and booting of
the SIMATIC PCS 7 BOX station. This is where you select the modules to use for
your PCS 7 project.
Note
The CP 5611 module is set for production operation in the CW based on the
connection of the PDM (via an ES in the PCS 7 network or SIMATIC PCS 7 BOX
station).
The authorization for the PDM software must be ordered separately to activate the
PDM on the respective station.
Requirements
• Installation of PCS 7 V6.0 SP3
• Software WinAC 3.4 for SIMATIC S7 CPU 416-2 PCI
Follow These Steps:
Note
If the communication module CP 1512 is inserted in a PCMCIA slot, the Windows
2000 Professional Hardware Wizard for commissioning will be displayed.
Carry out the steps in the Wizards and register the module in the operating system.
1. Use the on-board CP 5611 module for your PCS 7 project by activating the
option "Use module in configured PC station for production".
2. Specify the slot in the "Index" field.
3. Use the on-board Ethernet network card for your PCS 7 project by activating
the option "Use module in configured PC station for production" and specifying
the slot in the "Index" field.
4. Select "PG operation" for the CP1512 module so that it is not used in your PCS
7 project although is physically present.
Additional Information
Manual PC Configurations and Authorizations
