Siemens SIMATIC PCS 7 BOX User Manual

Process Control System PCS 7 - PCS 7 BOX
A5E00272813-01
1-1
1 What is SIMATIC PCS 7 BOX?
SIMATIC PCS 7 BOX is a complete process control system consisting of an
engineering station (ES), operator station (OS) and automation system (AS).
SIMATIC PCS 7 BOX enables connection to distributed I/O via the integrated AS in
the form of a "CPU 416-2 PCI" PC card. SIMATIC PCS 7 BOX enables you to
economically construct an autonomous process control system with all of the
necessary components and standard software SIMATIC PCS 7 V6.0 SP3.
SIMATIC PCS 7 BOX was especially designed for small-scale plants and stand-
alone stations (package units) that can be used for agitators, mixers or water
treatment stations. SIMATIC PCS 7 BOX is also very attractive as a beginning
system for first-time users of SIMATIC PCS 7. You can also use SIMATIC PCS 7
BOX with an external engineering station or integrate it into an existing PCS 7
process control system. In the following illustration, SIMATIC PCS 7 BOX is shown
as a single station variant.
1
2
3
4
5
6
7
8
9
0
.
+/-
Clear
Enter
ESC
Info
MEAS
ULTRAMAT 6
S
63,29
36,72
o CAL oLIM oAR o CODE
24V DC
DP/PA-Link
PROFIBUS PA
PROFIBUS DPPROFIBUS DP
PDM OS
Simatic Net
CP 5611
on board
CPU 416-2
PCI + PS
PCMCIA
card
Ethernet
on board
ES
PROFIBUS MPI/DPPROFIBUS MPI/DP
SIMATIC PCS 7 BOX
MPI/
DP DP
