5.2 Configuring SIMATIC PCS 7 BOX in the PCS 7 Network
5.2.1 Overview of Commissioning and Configuration
A connection to the plant and terminal bus is made to integrate the
SIMATIC PCS 7 BOX station in an existing PCS 7 system.
The special features of this configuration variant are that the time synchronization
of the AS and OS in the SIMATIC PCS 7 BOX station can be performed by a time
master, such as SICLOCK TM, on the plant bus and that the communication is
possible between an AS in a PCS 7 network and the CPU 416-2 PCI in the
SIMATIC PCS 7 BOX station.
In the following overview, only the steps that deviate from the configuration variant
"SIMATIC PCS 7 BOX as single station system" and are marked in bold are
available as links. The other steps correspond to the "SIMATIC PCS 7 BOX as
single station system" configuration variant.
Commissioning/Configuration Steps
1
Configuring the PC Station Using the Commissioning Wizard
2
Configuring the PC Using the Component Configurator
3
Adding a SIMATIC PCS 7 BOX Station to Your PCS 7 Project
4
Configuring NetPro
5
Synchronizing the Time on the AS via the Plant Bus
6
Synchronizing the Time on the AS via the Plant Bus
7
Configuring AS-AS Communication
8 Checking if the PG/PC interface is set to "PC internal"
9 Opening the operator panel of the CPU 416-2 PCI
10
Compiling and Downloading the AS and OS Data
11 Setting the CPU 416-2 PCI to RUN
The configuration tasks should be carried out in the order they appear.
