Commissioning and Configuration
Process Control System PCS 7 - PCS 7 BOX
4-8 A5E00272813-01
4.2.5 Step 5: Setting the Hardware Configuration of PC Stations
Once you completed the configuration of your PCS 7 project, you need to insert a
CP 5611 in HW Config of the PC station.
Requirements
• A "New Project" has been created in the PCS 7 Wizard.
• The PCS 7 project is open in the component view of the SIMATIC Manager.
Follow These Steps:
1. Mark the SIMATIC PC station in the left project window, open the context
menu with a right mouse click and select the command "Open Object".
2. In HW Config, navigate to the CP 5611 in the hardware catalog under
SIMATIC PC Station\CP-PROFIBUS and double-click on the CP 5611 folder.
Press the right mouse button and drag the marked CP (SW V6.0 SP5...) to the
slot in the station window that you selected in the Component Configurator and
click "OK".
3. Right click on the CPU 416-2 PCI in the station window to open the context
menu and select the command "Object Properties".
- Go to the "Diagnostics / Clock" tab.
- Under "Synchronization in AS:" in the clock section, select "As slave" as
the synchronization mode.
- Close the dialog window with the "OK" button.
4. Save and compile your changes and close HW Config.
Note
Make sure the settings in the Component Configurator match those in the
HW Config or your PCS 7 project.
Additional Information
STEP 7 online help
