Structure of SIMATIC PCS 7 BOX
Process Control System PCS 7 - PCS 7 BOX
3-6 A5E00272813-01
3.4 Configuration Variants for SIMATIC PCS 7 BOX
3.4.1 Configuration Possibilities
The following three configuration variants are recommended for the Box PC 620:
• SIMATIC PCS 7 BOX as single station system (single station variant) with
AS/ES/OS
• SIMATIC PCS 7 BOX as AS/OS with an external ES
• SIMATIC PCS 7 BOX as AS/OS in a PCS 7 network
Note
In all three configuration variants, the OS with WinCC should be regarded as a
single station OS and not a client/server system.
Additional Information
• SIMATIC PCS 7 BOX as Single Station System
• SIMATIC PCS 7 BOX with External Engineering Station
• SIMATIC PCS 7 BOX in a PCS 7 network
