Columns Content Function
Sequencer Name of the current sequencer. Display
The icon of the operating state (of the
sequencer) is indicated in front of the
name of the active sequencer. You can
find additional information about this in
the section: Icons for Operating States
(Page 95).
Display
SF "Step error" display Display
Step Name of the first active step Clicking this name opens the
detail view of the SFC with
the active step centered.
Icon for the step status: Display
INACTIVE not executed
INACTIVE, running
ACTIVE
HELD
ERROR
Comment Comment of the first *) active step Display
Runtime Runtime of the first *) active step Display
Transition Name of the first **) active transition Clicking this name opens the
detail view of the SFC with
the active transition centered.
Symbolic display of the result (colored
line)
CPU SFC- Status in the CPU after CPU
Stop/Run
SFC/CPU stop Display
SFC start with consistent data
SFC start with inconsistent data
IE Display for an interconnection error
(if error exists, otherwise empty box)
Display
OE Display for operating error
(if error exists, otherwise empty box)
Display
*) Several steps can be active at the same time in a simultaneous sequencer.
**) Several transitions can be active at the same time in an alternative sequencer.
Operating and monitoring SFCs
6.15 PCS 7 SFC MultiChart Control
SFC Visualization (V9.0)
54 Programming and Operating Manual, 05/2017, A5E41356392-AA
