Siemens SIMATIC RF615R - Technical Specifications

Readers
5.2 SIMATIC RF615R
SIMATIC RF600
112 System Manual, 11/2018, J31069-D0171-U001-A21-7618
5.2.5 Technical specifications
Table 5- 10 Technical specifications of the RF615R reader
6GT2811-6CC10-xAA0
Product type designation
SIMATIC RF615R
Radio frequencies
Operating frequency
• ETSI • 865 to 868 MHz
• FCC • 902 to 928 MHz
• CMIIT • 920 to 925 MHz
Transmit power
1)
• ETSI • 3 ... 400 mW
• FCC • 3 ... 400 mW
• CMIIT • 3 ... 400 mW
Maximum radiated power per antenna
• ETSI • 1000 mW ERP
• FCC • 1400 mW EIRP
• CMIIT • 1000 mW ERP
Electrical data
Range (internal antenna)
• ETSI • ≤ 1 m
• FCC • ≤ 1 m
• CMIIT • ≤ 1 m
Protocol
ISO 18000-62/-63
Transmission speed
≤ 300 kbps
Frequency accuracy
≤ ±10 ppm
Channel spacing
• ETSI • 600 kHz
• FCC • 500 kHz
• CMIIT • 250 kHz
Modulation methods ASK: DSB modulation & PR-ASK modulation
encoding, Manchester or Pulse Interval (PIE)
Multitag capability
Yes
