Antennas
6.2 SIMATIC RF615A
SIMATIC RF600
224 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.2.8 Dimension drawing
Figure 6-11 Dimension drawing RF615A
All dimensions in mm
6.2.9 Certificates & approvals
Table 6- 8 6GT2812-0EA00
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
Table 6- 9 6GT2812-0EA01
This product is UL-certified for the USA and Canada.
It meets the following safety standard(s):
• UL Report E115352
• UL 62368-1 - AVICT Equipment - Part 1: Safety Requirements
• CSA C22.2 No. 62368-1-14 AVICT Equipment - Part 1: Saftey
Requirements
