Transponder
7.15 SIMATIC RF682T
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
441
Delivery format
The SIMATIC RF682T is available in the following form:
● 10 transponders per packaging unit
Minimum order quantity: 1 packaging unit
The mounting set for SIMATIC RF682T is available in the following form:
● 10 mounting sets per packaging unit
Minimum order quantity: 1 packaging unit
7.15.3 Planning operation
7.15.3.1 Optimum antenna/transponder positioning with plane mounting of the transponder on
metal
Figure 7-42 Example of optimum antenna/transponder positioning
7.15.3.2 Note on installation
Reduction of the write/read range
When mounting on metal or conductive material, ensure that the space below the
transponder remains empty.
