Antennas
6.7 SIMATIC RF660A
SIMATIC RF600
304 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.7.6 Antenna patterns
Spatial directional radiation pattern
The following schematic diagram shows the main and auxiliary fields of the RF660A antenna
in free space in the absence of reflecting/absorbing materials. Please note that the diagram
is not to scale.
The recommended working range lies within the main field that is shown in green.
Main field (processing field)
Secondary fields
Figure 6-48 Main and auxiliary fields of the RF660A antenna
