Transponder
7.15 SIMATIC RF682T
SIMATIC RF600
440 System Manual, 11/2018, J31069-D0171-U001-A21-7618
7.15 SIMATIC RF682T
7.15.1 Characteristics
The heat-proof SIMATIC RF682T is a passive and maintenance-free data carrier. The
RF682T operates based on the UHF Class 1 Gen 2 technology and is used to store the
"Electronic Product Code" (EPC) of 224 bits. The transponder also has a 3072-bit user
memory.
These transponders with a limited service life are ideally suited to high-temperature
applications (e.g. the painting of vehicle bodies) as well as applications in production
logistics.
The RF682T is rugged and suitable for industrial applications with degree of protection
IP68/IPX9K. It is highly resistant to oil, grease and cleaning agents.
The SIMATIC RF682T is mounted directly onto metal surfaces to ensure optimum
functioning.
Area of application Applications with high temperatures (briefly up to
+220 °C).
Typical areas of application:
• Paint shops and their preparatory treatments,
incl. drying ovens
• Electrophoretic deposition area
• Primer coat incl. drying oven
• Top coat area incl. drying oven
• Washing areas at temperatures > 85 °C
Air interface According to ISO 18000-63
Memory
• EPC: 28 bytes / 224 bits
• User memory: 384 bytes / 3072 bits
Read range Max. 3.5 m
1)
Only intended for mounting directly on metal.
1)
Depending on the environment, the reader/the antennas and the set power
7.15.2 Ordering data
Table 7- 59 Ordering data
Mounting set for SIMATIC RF68xT
6GT2890-2AA00
