Antennas
6.8 SIMATIC RF680A
SIMATIC RF600
314 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.8.4 Connecting the antenna
The SIMATIC RF680A antenna must be connected to the reader using an antenna cable.
Preassembled standard cables in lengths of 1 m, 3 m, 5 m, 10 m, 15 m, 20 m and 40 m are
available to connect the antenna.
NOTICE
Connecting the antenna
Do not connect the adaptive antenna RF680A during operation. Only connect the antenna
to a reader that has been turned off and then restart the reader.
The range of the antenna is limited by the cable loss. The maximum range can be achieved
with the cable 6GT2815-0BH10 (length 1 m), since this cable has the lowest cable loss.
Requirement
Note
Use of Siemens antenna cables
To ensure optimum functioning of the ant
enna, it is recommended that a Siemens antenna
cable be used in accordance with the list of accessories.
