Siemens SIMATIC RF615R User Manual

SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
95
Readers
5
5.1 Overview
The following table shows the most important features of the stationary RF600 readers at a
glance:
Table 5- 1 Characteristics of the readers
Characteristics
SIMATIC RF615R
SIMATIC RF650R
SIMATIC RF680R
SIMATIC RF685R
Air interface /
standards supported
ISO 18000-62
ISO 18000-63
Radio profile variants ETSI, FCC, CMIIT ETSI, FCC, CMIIT,
ARIB (STD-T107)
ETSI, FCC, CMIIT,
ARIB (STD-T106)
LEDs 7 6 17
Interfaces
Number of external
antennas via RTNC
1 4 1
Available internal
antennas
1 -- 1
Ethernet 1 x M12 connector
(4-pin)
1 x RJ45 connector (8-
pin)
according to
IEC PAS 61076-3-117
2 x M12 connector (4-pin)
PROFINET
✓
--
✓
RS-422 1 x plug
(M12, 8-pin)
1)
-- 1 x plug
(M12, 8-pin)
1)
Digital inputs 1 x (M12, 4-pin)
log "0": 0…7 V
log "1": 15…24 V
4 x (M12, 12-pin)
log "0": 0…7 V
log "1": 15…24 V
Digital outputs
(short-circuit-proof)
1 x (M12, 4-pin) 4 x (M12, 12-pin)
Power supply 24 V DC (M12, 8-pin)
20…30 V (0.3 A)
external
24 V DC (M12, 8-pin)
20…30 V (2 A)
external
Max. radiated power
ETSI in ERP
200 mW ERP
2)
1 W ERP
2 W ERP 2 W ERP
2)
2 W ERP
Max. radiated power
CMIIT in ERP
250 mW ERP
2)
1 W ERP
2 W ERP 2 W ERP
2)
2 W ERP
Max. radiated power
FCC in EIRP
400 mW EIRP
2)
1.4 W EIRP
4 W EIRP 4 W EIRP
2)
4 W EIRP
Max. radiated power
ARIB in EIRP
-- 0.5 W EIRP 4 W EIRP
