Antennas
6.4 SIMATIC RF640A
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
247
Table 6- 18 Bending radii and bending cycles of the antenna cable
Cable designa-
tion
Article number
Length [m]
Cable loss [dB]
Bending radius
[mm]
1)
Antenna cable
6GT2815-0BH10
1
0.5
51
Antenna cable 6GT2815-0BH30 3 1 51
Antenna cable
(suitable for drag
chains)
6GT2815-2BH50 5 1.5 44
2)
Antenna cable
6GT2815-1BN10
10
2
77
Antenna cable
6GT2815-0BN10
10
4
51
Antenna cable
(suitable for drag
chains)
6GT2815-2BN15 15 4 44
2)
Antenna cable
6GT2815-0BN20
20
4
77
Antenna cable
6GT2815-0BN40
40
5
77
1)
Permissible minimum bending radius with multiple bending.
2
)
With cables capable of being used in drag chains, 100,000 bending cycles at a bending radius of
100 mm and a bend of ± 180° or 3 million torsion cycles with a bend of ± 180° on a cable length of
1 m are permitted.
6.4.5 Antenna parameter assignment
6.4.5.1 Setting RF640A parameters for RF650R
Depending on the country or region in which the antenna is being operated, it is subject to
regional limitations with respect to the radiated power.
Limitations in the EU, EFTA, or Turkey
Note
Limitation of the radiated power according to EN 302 208 V1.4.1 (ETSI)
RF600 systems that are put into operation in the EU, EFTA or Turkey
must not exceed the
following radiated power with an RF640A antenna:
•
2000 mW ERP (or 33 dBm ERP)
Converted into EIRP: 3250 mW EIRP (or 35 dBm EIRP)
