Transponder
7.7 SIMATIC RF610T ATEX
SIMATIC RF600
380 System Manual, 11/2018, J31069-D0171-U001-A21-7618
7.7.5 Dimension drawing
Figure 7-16 Dimension drawing SIMATIC RF610T (special variant ATEX)
All dimensions in mm
7.7.6 Certificates and approvals
Conformity with the ATEX directive 2014/34/EU based on:
Conformity statement no. TÜV 11 ATEX 081778 X
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
Federal Communications
Passive labels and transponders comply with the valid regulations;
certification is not required.
