Siemens SIMATIC RF615R User Manual

Antennas
6.2 SIMATIC RF615A
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
219
Directional radiation pattern of the RF615A (FCC) on metallic mounting surface (15 cm x 15 cm)
Pattern of the vertical plane of the antenna
Pattern of the horizontal plane of the antenna
Figure 6-9 Directional radiation pattern of the RF615A (FCC) on metallic mounting surface
