Siemens SIMATIC RF615R User Manual

Antennas
6.3 SIMATIC RF620A
SIMATIC RF600
238 System Manual, 11/2018, J31069-D0171-U001-A21-7618
Directional radiation pattern of the RF620A (FCC) on non-metallic mounting surface
Pattern of the vertical plane of the antenna
Pattern of the horizontal plane of the antenna
Figure 6-21 Directional radiation pattern of the RF620A (FCC) on non-metallic mounting surface

Siemens SIMATIC RF615R Specifications

General

Brand	Siemens
Model	SIMATIC RF615R
Category	Rfid Systems
Language	English
