Antennas
6.3 SIMATIC RF620A
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
241
6GT2812-1EA0x
Electrical data
Range See section "Maximum read/write ranges of
transponders (Page 341)"
Impedance
50 Ω
Polarization
Linear
VSWR (standing wave ratio)
≤ 2:1
Power
• ETSI • ≤ 2 W
• FCC • ≤ 1 W
Interfaces
Plug connection 30 cm coaxial cable with RP-TNC coupling
(for connection of the antenna cable)
Mechanical specifications
Material
PA 12
Color
Pastel turquoise
Tightening torque (at room temperature)
≤ 2 Nm
Permitted ambient conditions
Ambient temperature
• During operation • -20 ... +70 °C
• During transportation and storage • -40 ... +85 °C
Degree of protection IP67
Shock resistant to EN 60068-2-27 50 g
2)
Vibrations according to EN 60068-2-6 20 g
2)
Design, dimensions and weight
Dimensions (H x W x D) 75 x 75 x 20 mm
Weight
100 g
Standards, specifications, approvals
Proof of suitability
• ETSI • CE (ETSI EN 302208)
• FCC • FCC (Title 47, Part 15.247), cULus
MTBF
1190 years
1)
The values differ for different dimensions/materials of the mounting surface.
2)
The values for shock and vibration are maximum values and must not be applied continuously.
