Siemens SIMATIC RF615R User Manual

Antennas
6.5 SIMATIC RF642A
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
269
Table 6- 24 Bending radii and bending cycles of the antenna cable
Cable designa-
tion
Article number
Length [m]
Cable loss [dB]
Bending radius
[mm]
1)
Antenna cable
6GT2815-0BH10
1
0.5
51
Antenna cable 6GT2815-0BH30 3 1 51
Antenna cable
(suitable for drag
chains)
6GT2815-2BH50 5 1.5 44
2)
Antenna cable
6GT2815-1BN10
10
2
77
Antenna cable
6GT2815-0BN10
10
4
51
Antenna cable
(suitable for drag
chains)
6GT2815-2BN15 15 4 44
2)
Antenna cable
6GT2815-0BN20
20
4
77
Antenna cable
6GT2815-0BN40
40
5
77
1)
Permissible minimum bending radius with multiple bending.
2
)
With cables capable of being used in drag chains, 100,000 bending cycles at a bending radius of
100 mm and a bend of ± 180° or 3 million torsion cycles with a bend of ± 180° on a cable length of
1 m are permitted.
