Antennas
6.5 SIMATIC RF642A
SIMATIC RF600
278 System Manual, 11/2018, J31069-D0171-U001-A21-7618
Directional radiation pattern of the RF642A in the FCC frequency band
Pattern of the vertical plane of the antenna
Pattern of the horizontal plane of the antenna
Figure 6-38 Directional radiation pattern of the RF642A in the FCC frequency band
