Antennas
6.8 SIMATIC RF680A
SIMATIC RF600
324 System Manual, 11/2018, J31069-D0171-U001-A21-7618
Radiation diagram circular in the FCC frequency band
Pattern of the vertical plane of the antenna
Pattern of the horizontal plane of the antenna
Figure 6-60 Directional radiation pattern of the RF680A in the FCC frequency band
