Siemens SIMATIC RF615R User Manual

Accessories
10.1 Wide-range power supply unit for SIMATIC RF systems
SIMATIC RF600
472 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6GT2898-0ACx0
Regulation
• Line regulation • ≤ 1.0%
at U
in
= min./max.
• Load regulation • ≤ 1.0%
at I
out
= 10...90...10%
Short-circuit current I
max
105 ... 130 % I
nom
at I
nom
= 3 A (+50 °C)
Settling time t
R
load variations < 5 ms
at I
out
= 10...90...10 %
Temperature coefficient ε 0.01 % / K
at T
A
= -25 °C ... +70 °C
Overload behavior P
over
Constant current
Short-circuit protection/
No-load response
Continuous/no-load stability
Derating 2 % / K
at T
A
> +50 °C ... +70 °C
Connector type M12, 4-pin
two sockets
Table 10- 7 Output configurations
Input
Outputs
U1 = U2
ILoad = I1 + I2
Efficiency (%)
Remarks
110 VAC
24 VDC
0 A
--
No-load protection
110 VAC
24 VDC
3 A
≥ 88
--
220 VAC
24 VDC
0 A
--
No-load protection
220 VAC
24 VDC
3 A
≥ 90
--
All values are measured at full-load and at an ambient temperature of 25 °C (unless
specified otherwise).
