Technical specifications
A.2 Fail-Safe CPU technical specifications
S7-1200 Functional Safety Manual
160 Manual, 02/2015, A5E03470344-AA
A.2.3
CPU 1215FC
A.2.3.1
General specifications and features
Table A- 26 General
Technical data
CPU 1215FC
DC/DC/Relay
CPU 1215FC
DC/DC/DC
Article number
6ES7 215-1HF40-0XB0
6ES7 215-1AF40-0XB0
Dimensions W x H x D (mm) 130 x 100 x 75
Shipping weight
550 grams
520 grams
Power dissipation 12 W
Current available (SM and CM bus)
1600 mA max. (5 VDC)
Current available (24 VDC)
400 mA max. (sensor power)
Digital input current consumption (24 VDC)
4 mA/input used
Table A- 27 CPU features
Technical data
Description
User memory
(Refer to "General
technical specifica-
tions (Page 132),
"Internal CPU
memory reten-
tion".)
Work
150 Kbytes
Load
4 Mbytes, internal, expandable up to SD card size
Retentive 10 Kbytes
On-board digital I/O
14 inputs/10 outputs
On-board analog I/O
2 inputs/2 outputs
Process image size
1024 bytes of inputs (I)/1024 bytes of outputs (Q)
Bit memory (M)
8192 bytes
Temporary (local) memory
• 16 Kbytes for startup and program cycle (including associated FBs and FCs)
• 6 Kbytes for each of the other interrupt priority levels (including FBs and FCs)
Signal modules expansion
8 SMs max.
SB, CB, BB expansion
1 max.
Communication module expansion
3 CMs max.
High-speed counters Up to 6 configured to use any built-in or SB inputs. (Refer to the S7-
1200 System
Manual for more information.)
• 100/
1
80 kHz (Ia.0 to Ia.5)
• 30/
1
20 kHz (Ia.6 to Ib.5)
Pulse outputs
2
Up to 4 configured to use any built-in or SB outputs
• 100 kHz (Qa.0 to Qa.3)
• 30 kHz (Qa.4 to Qb.1)
Pulse catch inputs 14
