Getting started
2.1 Introduction to example
S7-1200 Functional Safety Manual
26 Manual, 02/2015, A5E03470344-AA
2.1.2
Requirements for configuring and programming
These instructions will guide you step-by-step through a specific example for configuring and
programming with STEP 7 Safety V13 SP1 or later.
You will become acquainted with the basic functions and special features of STEP 7
Safety V13 SP1 or later.
It should take one or two hours to work through this example, depending on your experience.
Requirements for the example
The following requirements must be met:
● You must have "Adobe Reader Version 9" or higher and "Adobe Flash Player 11 Active
X" software loaded on your computer in order to operate the multi-media content.
● In order to understand these Getting Started instructions, you need general knowledge of
automation technology. You also need to be familiar with STEP 7 V13 SP1 or later and
STEP 7 Safety V13 SP1 or later.
● You need an S7-1200 station consisting of the following components:
– Fail-safe CPU (CPU 1214FC or CPU 1215FC)
– Fail-safe digital input signal module: SM 1226 F-DI 16 x 24 VDC
– Fail-safe digital output signal module: SM 1226 F-DQ 4 x 24 VDC
● STEP 7 V13 SP1 or later and STEP 7 Safety V13 SP1 or later must be correctly installed
on your Windows-based programming device with an Ethernet interface.
● The programming device must be connected to the fail-safe CPU through the PROFINET
interface.
● The CPU 1214FC or CPU 1215FC and other hardware must be fully installed and wired.
Instructions for this can be found in the "S7-1200 Programmable Controller System
Manual" (http://support.automation.siemens.com/WW/view/en/91696622)
.
WARNING
As a component in plants and systems, the S7-1200 is subject to specific standards and
regulations depending on the area of application. Please note the applicable safety and
accident prevention regulations (for example, IEC 60204-1 (General Requirements for
Safety of Machinery)).
The example in these Getting Started instructions serves as an introduction to configuring
and programming of STEP 7 Safety Advanced V13 SP1 or later. It does not lead to actual
live operation in every case. Before you do this, it is essential that you refer to the current
version of the "SIMATIC, Industrial Software, SIMATIC Safety - Configuring and
Programming, Programming and Operating Manual"
(http://support.automation.siemens.com/WW/view/en/54110126/0/en). The warnings and
other notes contained in that manual must be heeded at all times even if they are not
repeated in this document!
Serious injury and damage to machines and equipment may result if these regulations are
ignored.
