INSTALLATION
3-3
Hardware
and Installation User Manual
3.1.1 Installing
Base Har
dware
For rack or panel mounting, place the brackets in the desired position on the
Series 505 base (on the front for rack mounting, or on the back for panel
mounting) as shown in Figure 3-2. Insert the enclosed screws through the
brackets
into the predrilled holes in the base and tighten.
3.1.2
Rack or Panel Mounting
If
you are mounting your base on a predrilled rack, align the brackets with the
rack,
then insert and tighten the screws.
Before mounting the base to a panel, you need to measure for and drill screw
holes.
Refer to Figure 3-2 for screw locations.
On the front of the base is a ground lug which you should connect to a
single-point earth ground. (Refer to Appendix B for further grounding
guidelines.)

Each
base has a plastic
dustguard covering the top grill.
The
dustguard prevents debris from falling into the
base
during installation. After the entire system installation
is complete, and BEFORE ENABLING POWER TO THE
SYSTEM, be sure to remove the dustguard from each
base.
This will allow proper air flow
and prevent serious
complications due to overheating.
