A-1
Hardware
and Installation User Manual
APPENDIX A
SPECIFICATIONS
Environmental Specifications
Operating Temperature
Relative Humidity
5% to 95% noncondensing
Vibration
Sinusoidal: IEC 68–2–6,
T
est Fc;
Random: NA
VMAT
P–9492 or
Impact Shock
IEC, 68–2–27,
T
est Ea; Half sine, 15g, 1
1 ms
Pollution degree
2, IEC664, 664A
Corrosion Protection
All parts are of corrosion-resistant material
or are plated or painted as corrosion
protection.
User Memory Capacity
2K, 4K, 8K, or 12K of RLL
memory,
depending on the model.
General Specifications
Input Power
Provided by power supply module
10 W @ +5 VDC, 0.5 W @ –5 VDC
Electric Noise Immunity
Conducted noise: IEC 801, Part 4, Level 3
MIL–STD–461B, Part 4;
CS01, CS02, CS06
IEC 255–4,
Appendix E
IEEE 472, 2.5 kV
Radiated noise: IEC 801 Part 3, Level 3
MIL–STD–461B, Part 4;
RS01, RS02
Electrostatic discharge:
IEC 801, Part 2,
(15 KV)
Battery Backup
3.0 V lithium battery (PPX:2587678–8005)
Communication Ports
RS-232-C/RS-423: all models
0.15 mm peak to peak,
10–57 Hz;
1.0 g, 57–150 Hz
2
/Hz, 80–350 Hz, and
IEC 68–2–34,
0.04g
3dB/octave rollof
f,
80–20 Hz and
350–2000 Hz at 10 min/axis
T
est Fdc with
Storage T
emperature
EEC 4517/79 Com(78) 766 Final, Part 4
Level 4
(All P/C models and power supply)
(All P/C models)
Isolation (user-side to PLC-side): 1500 V
rms
UL
Listed (industrial control equipment)
CSA
Certified (process control equipment)
Agency
Approvals
(All PLC models and power supply)
System Isolation
Maximum power drawn from base by
TI525:
12.5 W @ +5 VDC, 0.2 W @ –5 VDC
Maximum power drawn from base by
TI535:
Memory Backup
EEPROM (PPX:2587681–8020)
Battery backed-up static RAM
PPX:505–6660
for user-supplied 1
10/220 V
AC.
PPX:505–6663 for user-supplied 24 VDC.
–405 to 705C; –405 to 1585F
05 to 605C; 325 to 1405F
3 years typical storage (05 to 605C)
6 months typical storage (05 to 605C)
RS422:
PPX:525–1208, PPX:525–1212
PPX:535–1204, PPX:535–1212
