INSTALLATION
3-31
Hardware
and Installation User Manual
Table 3-2 I/O Module Point Assignments
(Continued on next page)
Model Model Points Special Slots
Number Description Used Function Used
PPX:505–4008 20–56
V
AC Input
8X 1
PPX:505–4016
20–56 V
AC Input
16X 1
PPX:505–4032
20–56 V
AC Input
32X 1
PPX:505–4108
4.5–15 VDC Input
8X 1
PPX:505–4116
4.5–15 VDC Input
16X 1
PPX:505–4132
4.5–15 VDC Input
32X 1
PPX:505–4208
79–132 V
AC Input
8X 1
PPX:505–4216
79–132 V
AC Input
16X 1
PPX:505–4232
79–132 V
AC Input
32X 1
PPX:505–4308
14–32 VDC Input
8X 1
PPX:505–4316
14–32 VDC Input
16X 1
PPX:505–4317
16 Isolated Inputs or
8 Interrupt Inputs/8 Isolated Inputs
16X 1
PPX:505–4332
14–32 VDC Input
32X 1
PPX:505–4408
164–256 VDC Input
8X 2
PPX:505–4416
164–256 VDC Input
16X 1
PPX:505–4432
164–256 VDC Input
32X 1
PPX:505–4508
4.5–34 VDC, 0.5 Amp Output
8Y 1
PPX:505–4516
4.5–34 VDC, 0.5 Amp Output
16Y 1
PPX:505–4532
4.5–34 VDC, 0.5 Amp Output
32Y 1
PPX:505–4608
20–132 V
AC, 0.5 Amp Output
8Y 1
PPX:505–4616
20–132 V
AC, 0.5 Amp Output
16Y 1
PPX:505–4632
20–132 V
AC, 0.5 Amp Output
32Y 1
PPX:505–4708
4.5–34 VDC, 2.0 Amp Output
8Y 2
PPX:505–4716
4.5–34 VDC, 2.0 Amp Output
16Y 2
PPX:505–4732
4.5–34 VDC, 2.0 Amp Output
32Y 2
PPX:505–4808
85–256 V
AC, 2.0 Amp Output
8Y 2
PPX:505–4816
85–256 V
AC, 2.0 Amp Output
16Y 2
PPX:505–4832
85–256 V
AC, 2.0 Amp Output
32Y 2
PPX:505–4908
20–256 V
AC or 4.5–34 VDC
Form C Output
8Y 1
PPX:505–4916
20–256 V
AC or 4.5–34 VDC
Normally Open Output
16Y 1
PPX:505–4932
20–256 V
AC or 4.5–34 VDC
Normally Open Output
32Y 2
PPX:505–5417 1
15 VDC, Relay Output
16Y 1
