Description of system components
8.3 Operator panel with display
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
131
8.3.3.16 Reading the device's internal event memory
The "Event memory" menu item enables access to the SIMOCODE pro's internal event
memory. The two most recent events "DM-F enabling circuit closed" and "DM-F enabling
circuit open" are displayed, together with the time, for both digital modules "DM-F Local" and
"DM-F PROFIsafe".
Event memory
The event memory is displayed.
Last event "Enabling circuit closed," DM-F Local
The entry contains the last event "DM-F enabling circuit closed," the time and the related DIP
switch configuration.
Note
Requirements
Possible only if digital module 1 is used as a DM
-F Local module.
Last event "Enabling circuit closed," DM-F PROFIsafe
The entry contains the last event "DM-F enabling circuit closed," the time and the related
PROFIsafe address.
Note
Requirements
Possible only if digital module 1 is used as a DM
-F PROFIsafe module.
Last event "Enabling circuit open"
The entry contains the last event "DM-F enabling circuit open" and the corresponding time.
Note
Requirements
Possible only if digital module
1 is used as a DM-F Local or DM-F PROFIsafe module.
