If you need any other additional functions for your application, you can use the freely
programmable logic modules. These can be used, for example, to implement logical
operations, time relay functions and counter functions. Furthermore, limit monitors can
monitor any value in SIMOCODE pro for undershooting or overshooting of a freely selected
limit. Depending on the device series, the system provides several freely parameterizable
logic modules:
Table 5- 4 Freely-programmable logic modules
Logic module
SIMOCODE pro
BP
GP
HP
C
Number
S
Number
V PN GP
Number
V PB
Number
V MR
Number
V PN
Number
V EIP
Number
Truth table 3
inputs / 1 output
3 4 4 6 6 8 8
Truth
table 2 inputs /
1 output
— 2 2 2 2 2 2
Truth tables 5
inputs/2 outputs
— — — 1 1 1 1
Timers
2
2
2
4
4
6
6
Counters
2
2
2
4
4
6
6
Signal
conditioning
2 4 4 4 4 6 6
Non-volatile
elements
2 2 2 4 4 4 4
Flashing
3
3
3
3
3
3
3
Flicker
3
3
3
3
3
3
3
Limit monitor
—
—
—
4
4
6
6
Calculation
modules
(calculators)
— — — 2
1)
2 4 4
Analog
multiplexer
— — — — — 1 1
Pulse width
modulator
— — — — — 1 1
1) from version *E03*
Detailed description: See Chapter "Logic blocks" in the manual
Parameterizing SIMOCODE pro
(https://support.industry.siemens.com/cs/ww/en/view/109743958
).
