Siemens SIMOCODE pro C - Parameters

Description of system components
8.3 Operator panel with display
SIMOCODE pro
124 System Manual, 05/2019, A5E40507475002A/RS-AD/004
8.3.3.9 Parameters
You can set the following parameters using the operator panel with display:
Parameters
Range
Note
Overload protection → current settings
Possible only if a current measuring module is
configured
Current setting Is1
0.00 - 9,999.00 A
-
Current setting Is2 0.00 - 9,999.00 A Possible only in conjunction with the following control
functions:
• Dahlander starter
• Dahlander reversing starter
• Pole-changing starter
• Pole-changing reversing starter
Current limits
Possible only if a current measuring module is
configured
Monitoring of current limits → trip level I >
(upper limit)
0 - 1020 % of Is -
Monitoring of current limits → warning level
I > (upper limit)
0 - 1020 % of Is -
Monitoring of current limits → trip level I <
(lower limit)
0 - 1020 % of Is -
Monitoring of current limits → warning level
I < (lower limit)
0 - 1020 % of Is -
Motor protection → stalled rotor protection
level
0 - 1020 % of Is -
Voltage monitoring → voltage limits
Possible only if a current / voltage measuring module
is configured
Trip level U < (lower limit)
0 - 2040 V
-
Warning level U < (lower limit) 0 - 2040 V -
Cos phi monitoring → Cos phi limits
Possible only if a current / voltage measuring module
is configured
Trip level cos phi < (lower limit)
0 - 100 %
-
Warning level cos phi < (lower limit) 0 - 100 % -
Active power monitoring →
Active power limits
Possible only if a current / voltage measuring module
is configured
Trip level P > (upper limit) 0.000 -
9999.000 kW
-
Warning level P > (upper limit) 0.000 -
9999.000 kW
-
Trip level P < (lower limit) 0.000 -
9999.000 kW
-
Warning level P < (lower limit) 0.000 -
9999.000 kW
-
Ground fault monitoring → Ground fault limits
Possible only if a 3UF7510 ground-fault module is
configured
