Description of system components
8.12 Temperature module (TM)
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
153
8.12 Temperature module (TM)
The temperature module offers the option of expanding the SIMOCODE pro V/pro S device
series by an analog temperature monitoring system. In addition to the thermistor monitoring
system for the basic units, up to 3 analog sensor measuring circuits (in two or three-wire
systems) can be connected, the temperatures in the 3 sensor measuring circuits can be
measured, and the highest temperature in all sensor measuring circuits can be determined.
The temperatures recorded can be fully integrated and monitored in the process and can
also be transferred to a higher-level automation system via the communication bus.
You can, for example, implement analog temperature monitoring of the motor windings,
bearings, coolant or gearbox oil.
Various sensor types (NTC, KTY83/84, PT100/PT1000) for use with solid, liquid, or gaseous
media are supported.
Note
The same sensor type must be used in all sensor measuring circuits.
● 1 temperature module can be connected to the SIMOCODE pro V PB and pro V MR
basic units
● 1 temperature module with 1 sensor to the SIMOCODE pro S basic unit
● 2 temperature modules can be connected to the SIMOCODE pro V PN and pro V EIP
basic units
● 1 temperature module to the SIMOCODE pro V PN GP basic unit
● 3 sensor measuring circuits in 2 or 3-wire systems.
Note
Requirements for using a temperature module with SIMOCODE pro V PB
Use of a temperature module requires a SIMOCODE
pro V PB basic unit, at least version
or later (from 04/2005).
