Technical data
15.7 Technical data of the multifunction module
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
357
15.7 Technical data of the multifunction module
Technical data of the multifunction module
Mounting
Snap-mounted onto 35-mm standard mounting rail or screw-mounted using additional
push-in lugs
Cabinet mounting
Minimum distance to be maintained
• from cabinet rear wall for series mounting at side: 0 mm
• from grounded parts at side: 2 mm
Display
Green "READY" LED
• Continuous light: "Ready for operation"
• Flashing: "No connection to basic unit"
System interfaces
For connection to a SIMOCODE pro S basic unit or an operator panel
Digital module function
Control circuit
Rated insulation voltage U
i
300 V (at pollution degree 3)
Rated impulse withstand
voltage U
imp
4 kV
Inputs (binary) 4 externally supplied, isolated inputs (24 V DC or 110 V to 240 V AC / DC, depending on
the type), connected to common potential for measuring process signals (e.g. local
control station, key-operated switches, limit switches, ...), freely-assignable to control
functions.
• 24 V DC:
Cable lengths (single)
Input characteristic
300 m
Type 2 according to EN 61131-2
• 110 V to 240 V AC/DC:
Cable lengths (single)
Input characteristic
200 m (cable capacitance 300 nF / km)
—
Relay outputs
• Number
2 monostable relay outputs (depending on the type)
• Function
Isolated NO contacts (NC contact response parameterizable via internal signal
conditioning), relay outputs all with connection to common potential, freely-assignable to
control functions (e.g. line, star or delta contactor or operating state status information).
• Stipulated short-circuit
protection for auxiliary
contacts (relay outputs)
• Fuse links, operating class gL/gG 6 A, quick-response 10 A (IEC 60947-5-1)
• Miniature circuit breaker 1.6 A, C characteristic (IEC 60947-5-1)
• Miniature circuit breaker 6 A, C characteristic (I
k
< 500 A)
• Rated uninterrupted current • 5 A
• 6 A at max. +50 °C
• Rated switching capacity
AC-15 6 A / 24 V AC;
6 A / 120 V AC;
3 A / 230 V AC
