Technical data
15.6 Technical data of the expansion modules
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
347
Technical data of the digital modules
Inputs (binary)
4 externally supplied, isolated inputs (24 V DC or 110 V to 240 V AC / DC,
depending on the type), connected to common potential for measuring
process signals (e.g. local control station, key-operated switches, limit
switches, ...), freely-assignable to control functions.
• 24 V DC:
Cable lengths (single)
Input characteristic
300 m
Type 2 according to EN 61131-2
• 110 V to 240 V AC/DC:
Cable lengths (single)
Input characteristic
200 m (cable capacitance 300 nF / km)
—
Connection
Removable terminal block with screw connection
• Tightening torque
TORQUE: 7 LB.IN to 10.3 LB.IN 0.8 Nm - 1.2 Nm
• Connection cross sections
- Solid 2 x 0.5 mm
2
to 2.5 mm
2
/ 1 x 0.5 mm
2
to 4 mm
2
2 AWG 20 to 14 / 1 x AWG 20 to 12
- Finely stranded with end sleeve 2 x 0.5 mm
2
- 1.5 mm
2
/ 1 x 0.5 mm
2
- 2.5 mm
2
2 x AWG 20 to 16 / 1 x AWG 20 to 14
15.6.2 Technical data, digital modules DM-F Local and DM-F PROFIsafe
Technical data of the DM-F Local and DM-F PROFIsafe digital modules
Mounting
Snap-mounted onto 35-mm standard mounting rail or screw-mounted using additional
push-in lugs
Enclosure width
45 mm
System interfaces
For connecting to a basic unit, an additional expansion module, a current measuring
module or a current / voltage measuring module or the operator panel
Rated control supply
voltage U
s
(according to
DIN EN 61131-2)
• 24 V DC
• 110 V to 240 V AC/DC, 50/60 Hz
Operating range
• 24 V DC: 0.8 to 1.2 x U
s
• 110 V to 240 V AC/DC: 0.85 to 1.1 x U
s
Power consumption
DM-F LOCAL:
• 24 V DC: 3 W
• 110 V to 240 V AC/DC: 9.5 VA/4.5 W
DM-F PROFIsafe:
• 24 V DC: 4 W
• 110 V to 240 V AC/DC: 11.0 VA/5.5 W
Protective separation according to
IEC 60947-1
Between relay enabling circuits / relay outputs and electronics
