Siemens SIMOCODE pro C User Manual

Description of system components
8.4 Current measuring modules (IM) for the SIMOCODE pro C, SIMOCODE pro S, and SIMOCODE pro V
device series
SIMOCODE pro
134 System Manual, 05/2019, A5E40507475002A/RS-AD/004
The current measuring module is connected to the basic unit via a connecting cable, which
also supplies the power. Current measuring modules up to 100 A are suitable for standard
rail mounting or can be fixed directly to the mounting plate using additional push-in lugs.
Basic units can be snapped directly onto the current measuring modules. Current measuring
modules up to 200 A can also be mounted on the standard mounting rail or, optionally, they
can be fixed directly to the mounting plate with the screw attachments that are integrated in
the enclosure. The current measuring module up to 630 A can only be mounted using the
integrated screw attachments.
Note
Current measuring modules with a current setting of up to 100
A can be connected to the
basic unit
mechanically and be installed as a unit (behind one another). Larger current
measuring modules can only be mo
unted separately.
