Mounting, wiring, connecting, system interfaces, configuration guidelines
12.1 Mounting
SIMOCODE pro
194 System Manual, 05/2019, A5E40507475002A/RS-AD/004
Figure 12-9 Mounting the operator panel with display
Tightening torque of the screws
To ensure that the panel will function correctly and is sealed to comply with IP54, the
tightening torque of the screws provided must not be set too high when mounting and the
seal must be properly fitted.
Note
Only one connecting cable is required for connecting the operator panel with display to
S
IMOCODE pro (see Chapter An overview of system components (Page 65)). Additional
wiring for the power supply or ground is not required.
